| Item No. | Cores X Sectional area mm² |
Cable outer diameter mm |
Copper weight kg/km |
Cable weight kg/km |
| 1 | 4G1.5 | 10.6 | 58 | 159 |
| 2 | 4G2.5 | 12.0 | 97 | 219 |
| 3 | 4G4 | 14.6 | 155 | 336 |
| 4 | 4G6 | 17.3 | 231 | 471 |
| 5 | 4G10 | 19.9 | 386 | 682 |
| 6 | 4G16 | 23.1 | 616 | 992 |
| 7 | 4G25 | 28.5 | 964 | 1530 |
| 8 | 4G35 | 32.7 | 1348 | 2063 |
| 9 | 4G50 | 38.4 | 1924 | 2894 |
| 10 | 4G1.0+(2X0.5) | 12.5 | 58 | 194 |
| 11 | 4G1.0+(2X0.75) | 12.7 | 64 | 204 |
| 12 | 4G1.5+(2X0.5) | 13.1 | 77 | 225 |
| 13 | 4G1.5+(2X0.75) | 13.4 | 84 | 235 |
| 14 | 4G1.5+(2X1.0) | 13.6 | 89 | 245 |
| 15 | 4G2.5+(2X0.5) | 14.1 | 116 | 283 |
| 16 | 4G2.5+(2X0.75) | 14.4 | 122 | 293 |
| 17 | 4G2.5+(2X1.0) | 14.6 | 128 | 303 |
| 18 | 4G2.5+(2X1.5) | 15.1 | 143 | 326 |
| 19 | 4G4+(2X0.75) | 16.4 | 180 | 400 |
| 20 | 4G4+(2X1.0) | 16.7 | 186 | 411 |
| 21 | 4G4+(2X1.5) | 17.1 | 201 | 433 |
| 22 | 4G6+(2X0.75) | 18.2 | 256 | 500 |
| 23 | 4G6+(2X1.0) | 18.5 | 262 | 511 |
| 24 | 4G6+(2X1.5) | 18.9 | 276 | 534 |
| 25 | 4G10+(2X1.0) | 20.8 | 417 | 709 |
| 26 | 4G10+(2X1.5) | 21.3 | 431 | 732 |
| 27 | 4G16+(2X1.0) | 23.4 | 647 | 987 |
| 28 | 4G16+(2X1.5) | 23.8 | 662 | 1011 |
| 29 | 4G25+(2X1.5) | 27.7 | 1010 | 1462 |
| 30 | 4G35+(2X1.5) | 30.7 | 1393 | 1909 |
| 31 | 4G50+(2X1.5) | 35.1 | 1970 | 2620 |
| 32 | 4G1.5+2X(2X0.75) | 14.9 | 109 | 285 |
| 33 | 4G1.5+2X(2X1.0) | 15.4 | 120 | 305 |
| 34 | 4G2.5+2X(2X0.75) | 15.8 | 148 | 342 |
| 35 | 4G2.5+2X(2X1.0) | 16.3 | 159 | 362 |
| 36 | 4G2.5+2X(2X1.5) | 17.1 | 188 | 407 |
| 37 | 4G4+2X(2X1.0) | 18.2 | 217 | 469 |
| 38 | 4G4+2X(2X1.5) | 19.0 | 247 | 514 |
| 39 | 4G6+2X(2X1.0) | 19.9 | 293 | 568 |
| 40 | 4G6+2X(2X1.5) | 20.7 | 322 | 614 |
| 41 | 4G10+2X(2X1.0) | 22.1 | 448 | 765 |
| 42 | 4G10+2X(2X1.5) | 22.9 | 477 | 811 |
| 43 | 4G16+2X(2X1.0) | 24.4 | 678 | 1042 |
| 44 | 4G16+2X(2X1.5) | 25.2 | 708 | 1169 |
