| Item No | Specification | No of conductor | Conductor diameter mm |
Insulation thickness mm |
Sheath thickness mm |
Insulation outer diameter mm |
Cable weight kg/km |
| 1 | 4mm² | 82 | 0.25 | 1.2 | 5.1 | 61 | 101 |
| 2 | 6mm² | 122 | 0.25 | 1.2 | 5.9 | 84 | 128 |
| 3 | 10mm² | 204 | 0.25 | 1.4 | 7.4 | 136 | 187 |
| 4 | 16mm² | 326 | 0.25 | 1.4 | 8.6 | 200 | 258 |
| 5 | 25mm² | 510 | 0.25 | 1.6 | 10.5 | 305 | 372 |
| 6 | 35mm² | 713 | 0.25 | 1.6 | 11.9 | 409 | 490 |
| 7 | 50mm² | 1018 | 0.25 | 1.6 | 13.5 | 560 | 651 |
| 8 | 70mm² | 1426 | 0.25 | 1.6 | 15.4 | 760 | 862 |
| 9 | 95mm² | 1935 | 0.25 | 1.8 | 17.8 | 1024 | 1140 |
| 10 | 120mm² | 2442 | 0.25 | 1.8 | 19.6 | 1273 | 1395 |
| 11 | 150mm² | 3055 | 0.25 | 2.0 | 21.9 | 1594 | 1735 |
| 12 | 185mm² | 1472 | 0.40 | 2.0 | 23.9 | 1936 | 2089 |
| 13 | 240mm² | 1910 | 0.40 | 2.2 | 27 | 2498 | 2696 |
