| Item No | Cores X Sectional area | Cable outer diameter/mm | Copper weight kg/km | Cable weight kg/km |
| 1 | 2X0.5mm² | 6.8 | 22.7 | 71 |
| 2 | 3G0.5mm² | 7.1 | 28.2 | 80 |
| 3 | 4G0.5mm² | 7.7 | 35.0 | 96 |
| 4 | 5G0.5mm² | 8.3 | 41.2 | 110 |
| 5 | 6G0.5mm² | 8.8 | 47.6 | 124 |
| 6 | 7G0.5mm² | 9.5 | 53.9 | 143 |
| 7 | 8G0.5mm² | 10.1 | 60.5 | 160 |
| 8 | 10G0.5mm² | 11.0 | 72.5 | 178 |
| 9 | 12G0.5mm² | 11.7 | 83.4 | 209 |
| 10 | 14G0.5mm² | 12.2 | 94.3 | 230 |
| 11 | 15G0.5mm² | 12.8 | 99.8 | 253 |
| 12 | 16G0.5mm² | 13.1 | 105.3 | 263 |
| 13 | 18G0.5mm² | 13.6 | 116.4 | 290 |
| 14 | 20G0.5mm² | 14.1 | 127.5 | 310 |
| 15 | 24G0.5mm² | 15.8 | 150.8 | 390 |
| 16 | 25G0.5mm² | 15.8 | 155.6 | 389 |
| 17 | 30G0.5mm² | 16.7 | 181.5 | 459 |
| 18 | 36G0.5mm² | 18.4 | 213.7 | 554 |
| 19 | 2X0.75mm² | 7.2 | 28.5 | 82 |
| 20 | 3G0.75mm² | 7.7 | 37.0 | 97 |
| 21 | 4G0.75mm² | 8.2 | 45.6 | 113 |
| 22 | 5G0.75mm² | 8.8 | 54.3 | 131 |
| 23 | 6G0.75mm² | 9.4 | 63.2 | 149 |
| 24 | 7G0.75mm² | 10.0 | 72.0 | 167 |
| 25 | 8G0.75mm² | 10.9 | 81.0 | 201 |
| 26 | 10G0.75mm² | 12.0 | 97.9 | 221 |
| 27 | 12G0.75mm² | 12.9 | 113.5 | 265 |
| 28 | 14G0.75mm² | 13.4 | 129.1 | 293 |
| 29 | 15G0.75mm² | 13.7 | 137.0 | 308 |
| 30 | 16G0.75mm² | 14.0 | 144.9 | 320 |
| 31 | 18G0.75mm² | 14.8 | 160.8 | 361 |
| 32 | 20G0.75mm² | 15.6 | 177.3 | 397 |
| 33 | 24G0.75mm² | 17.2 | 223.4 | 501 |
| 34 | 25G0.75mm² | 17.2 | 230.4 | 501 |
| 35 | 30G0.75mm² | 18.6 | 269.7 | 611 |
| 36 | 36G0.75mm² | 20.2 | 316.6 | 720 |
| 37 | 2X1.0mm² | 8.0 | 35.6 | 102 |
| 38 | 3G1.0mm² | 8.5 | 46.0 | 121 |
| 39 | 4G1.0mm² | 9.1 | 57.2 | 141 |
| 40 | 5G1.0mm² | 9.8 | 68.6 | 163 |
| 41 | 6G1.0mm² | 10.5 | 80.1 | 187 |
| 42 | 7G1.0mm² | 11.2 | 100.4 | 219 |
| 43 | 8G1.0mm² | 12.1 | 112.8 | 263 |
| 44 | 10G1.0mm² | 13.4 | 125.2 | 276 |
| 45 | 12G1.0mm² | 14.2 | 145.7 | 323 |
| 46 | 14G1.0mm² | 15.0 | 166.3 | 366 |
| 47 | 15G1.0mm² | 15.3 | 176.6 | 385 |
| 48 | 16G1.0mm² | 15.6 | 187.1 | 402 |
| 49 | 18G1.0mm² | 16.7 | 221.9 | 476 |
| 50 | 20G1.0mm² | 17.6 | 243.5 | 520 |
| 51 | 24G1.0mm² | 19.4 | 287.5 | 638 |
| 52 | 25G1.0mm² | 19.6 | 297.7 | 649 |
| 53 | 30G1.0mm² | 21.0 | 348.5 | 777 |
| 54 | 36G1.0mm² | 22.5 | 411.2 | 906 |
| 55 | 2X1.5mm² | 9.2 | 48.0 | 136 |
| 56 | 3G1.5mm² | 9.6 | 70.8 | 164 |
| 57 | 4G1.5mm² | 10.3 | 87.8 | 193 |
| 58 | 5G1.5mm² | 11.4 | 105.2 | 232 |
| 59 | 6G1.5mm² | 12.2 | 122.7 | 266 |
| 60 | 7G1.5mm² | 13.2 | 140.9 | 317 |
| 61 | 8G1.5mm² | 14.4 | 158.8 | 368 |
| 62 | 10G1.5mm² | 16.0 | 179.2 | 394 |
| 63 | 12G1.5mm² | 16.8 | 222.8 | 473 |
| 64 | 14G1.5mm² | 17.8 | 254.1 | 533 |
| 65 | 15G1.5mm² | 18.3 | 269.7 | 571 |
| 66 | 16G1.5mm² | 18.8 | 285.5 | 595 |
| 67 | 18G1.5mm² | 20.0 | 317.2 | 680 |
| 68 | 20G1.5mm² | 21.1 | 349.7 | 744 |
| 69 | 24G1.5mm² | 23.6 | 414.8 | 938 |
| 70 | 25G1.5mm² | 23.6 | 429.0 | 938 |
| 71 | 30G1.5mm² | 25.2 | 504.4 | 1120 |
| 72 | 36G1.5mm² | 27.8 | 596.7 | 1360 |
| 73 | 2X2.5mm² | 10.6 | 79.3 | 195 |
| 74 | 3G2.5mm² | 11.1 | 105.0 | 228 |
| 75 | 4G2.5mm² | 12.0 | 132.1 | 272 |
| 76 | 5G2.5mm² | 13.3 | 159.7 | 328 |
| 77 | 6G2.5mm² | 14.9 | 188.3 | 401 |
| 78 | 7G2.5mm² | 16.0 | 216.0 | 471 |
| 79 | 8G2.5mm² | 17.3 | 245.0 | 548 |
| 80 | 10G2.5mm² | 19.4 | 298.0 | 607 |
| 81 | 12G2.5mm² | 20.7 | 348.1 | 725 |
| 82 | 14G2.5mm² | 21.7 | 399.0 | 807 |
| 83 | 15G2.5mm² | 22.7 | 425.2 | 887 |
| 84 | 16G2.5mm² | 23.3 | 450.8 | 926 |
| 85 | 18G2.5mm² | 24.7 | 502.1 | 1053 |
| 86 | 20G2.5mm² | 25.8 | 553.5 | 1163 |
| 87 | 24G2.5mm² | 28.6 | 658.3 | 1412 |
| 88 | 25G2.5mm² | 28.6 | 681.9 | 1414 |
