阻燃，符合IEC60332-1-2
ce认证
多股裸铜线，符合IEC60228标准，5级
芯线标识：符合DIN47100颜色标准
| Item No. | Cores X Sectional area mm² |
Cable outer diameter mm |
Copper weight kg/km |
Cable weight kg/km |
| 1 | 1X2X0.14mm² | 4.3 | 8.8 | 22 |
| 2 | 2X2X0.14mm² | 5.8 | 14.7 | 37 |
| 3 | 3X2X0.14mm² | 6.4 | 18.4 | 47 |
| 4 | 4X2X0.14mm² | 6.9 | 22.3 | 55 |
| 5 | 5X2X0.14mm² | 7.4 | 26.3 | 63 |
| 6 | 6X2X0.14mm² | 7.9 | 27.8 | 65 |
| 7 | 7X2X0.14mm² | 7.9 | 30.6 | 70 |
| 8 | 8X2X0.14mm² | 8.7 | 40.4 | 92 |
| 9 | 10X2X0.14mm² | 10.2 | 49.6 | 116 |
| 10 | 12X2X0.14mm² | 10.6 | 55.9 | 132 |
| 11 | 16X2X0.14mm² | 11.8 | 69.8 | 165 |
| 12 | 20X2X0.14mm² | 12.9 | 84.0 | 195 |
| 13 | 25X2X0.14mm² | 14.4 | 101.4 | 237 |
| 14 | 1X2X0.25mm² | 4.7 | 11.5 | 27 |
| 15 | 2X2X0.25mm² | 6.5 | 19.9 | 46 |
| 16 | 3X2X0.25mm² | 7.1 | 25.5 | 59 |
| 17 | 4X2X0.25mm² | 7.7 | 34.2 | 73 |
| 18 | 5X2X0.25mm² | 8.5 | 40.6 | 89 |
| 19 | 6X2X0.25mm² | 9.3 | 47.0 | 105 |
| 20 | 7X2X0.25mm² | 9.3 | 51.6 | 112 |
| 21 | 8X2X0.25mm² | 10.2 | 58.0 | 129 |
| 22 | 10X2X0.25mm² | 11.7 | 71.5 | 157 |
| 23 | 12X2X0.25mm² | 12.2 | 81.6 | 180 |
| 24 | 16X2X0.25mm² | 11.4 | 103.2 | 172 |
| 25 | 20X2X0.25mm² | 14.9 | 125.2 | 269 |
| 26 | 25X2X0.25mm² | 16.6 | 152.3 | 327 |
| 27 | 1X2X0.34mm² | 4.9 | 13.6 | 30 |
| 28 | 2X2X0.34mm² | 7.0 | 23.9 | 55 |
| 29 | 3X2X0.34mm² | 7.5 | 34.0 | 70 |
| 30 | 4X2X0.34mm² | 8.1 | 41.9 | 84 |
| 31 | 5X2X0.34mm² | 8.9 | 50.0 | 102 |
| 32 | 6X2X0.34mm² | 9.8 | 58.2 | 120 |
| 33 | 7X2X0.34mm² | 9.8 | 64.4 | 130 |
| 34 | 8X2X0.34mm² | 10.7 | 72.6 | 150 |
| 35 | 10X2X0.34mm² | 12.5 | 89.7 | 187 |
| 36 | 12X2X0.34mm² | 12.9 | 103.1 | 209 |
| 37 | 16X2X0.34mm² | 14.4 | 131.4 | 265 |
| 38 | 1X2X0.5mm² | 5.3 | 17.5 | 36 |
| 39 | 2X2X0.5mm² | 7.6 | 34.1 | 69 |
| 40 | 3X2X0.5mm² | 8.2 | 44.8 | 87 |
| 41 | 4X2X0.5mm² | 9.1 | 55.9 | 108 |
| 42 | 5X2X0.5mm² | 10.0 | 67.2 | 131 |
| 43 | 6X2X0.5mm² | 11.0 | 60.5 | 128 |
| 44 | 7X2X0.5mm² | 11.0 | 69.6 | 142 |
| 45 | 8X2X0.5mm² | 12.0 | 99.2 | 194 |
| 46 | 10X2X0.5mm² | 14.1 | 122.8 | 242 |
| 47 | 12X2X0.5mm² | 14.5 | 142.1 | 273 |
| 48 | 16X2X0.5mm² | 16.1 | 182.7 | 346 |
| 49 | 1X2X0.75mm² | 5.9 | 23.2 | 46 |
| 50 | 2X2X0.75mm² | 8.3 | 45.5 | 85 |
| 51 | 3X2X0.75mm² | 9.1 | 61.2 | 112 |
| 52 | 4X2X0.75mm² | 10.1 | 77.3 | 141 |
| 53 | 5X2X0.75mm² | 11.1 | 93.6 | 171 |
| 54 | 6X2X0.75mm² | 12.2 | 110.1 | 202 |
| 55 | 1X2X1.0mm² | 6.5 | 29.3 | 56 |
| 56 | 2X2X1.0mm² | 9.6 | 57.5 | 112 |
| 57 | 3X2X1.0mm² | 10.6 | 78.2 | 148 |
| 58 | 4X2X1.0mm² | 11.5 | 99.3 | 181 |
